Connectivity Solutions
Solution
Wi-Fi Specification
Wi-Fi Host Interface
Form Factor
Type

SX-PCEAX
Wi-Fi 6E + Bluetooth 5.2 PCI Radio Module
- Industry's 1st tri-band Wi-Fi 6E module
- Latest Wi-Fi technology
- Highest throughput (2400 Mbps)

SX-SDMAX
Wi-Fi 6 + Bluetooth 5.3 SDIO Radio Module
- Plug and play for NXP-based platforms
- 10-15 year product lifecycle
- Industrial temperature support

SX-SDMAH
Wi-Fi HaLow SDIO Radio Module
- High-performance and long range sub-GHz Wi-Fi
- SDIO host interface for Linux embedded system
- SPI host interface for FreeRTOS embedded system

AP-100AH
Wi-Fi HaLow Access Point
- Long-range high data throughput
- Large-scale IP-based IoT WLAN
- Easy Wi-Fi HaLow installation
-1.png)
BR-500AC
Wi-Fi 5 2x2 Ethernet to Wi-Fi bridge
- WPA3-Enterprise security
- Payload QoS management
- Simple device configuration

WM-100
Wi-Fi 5 Dual-band Wireless Monitor
- Radio spectrum analyzer to detect non-Wi-Fi radio signal
- Wi-Fi site monitoring and logging
- Wi-Fi infrastructure optimization

SX-NEWAH
Wi-Fi HaLow Hostless Module
- Long range wireless for hostless IoT devices
- FreeRTOS SDK for user application integration
- SPI host interface for Linux embedded system

BR-100AH
Wi-Fi HaLow Enterprise Ethernet Bridge
- Ethernet device range extension by Wi-Fi HaLow
- Over Mbps data throughput over long distance
- WPA3-Enterprise security for enterprise IT

SX-SDMAC
Wi-Fi 5 + Bluetooth 5.0 SDIO Module
- Antenna diversity for robust connectivity
- Industrial temperature range
- On-board chip antenna option

SX-SDMAC Plus
Wi-Fi 5 + Bluetooth 5.0 SDIO Module
- Optimized for size and cost
- Extended temperature range
- Linux, Windows and FreeRTOS driver support

SX-SDPAC
Wi-Fi 5 + Bluetooth 5.0 SDIO System-in-Package
- Ideal for high-volume, low-cost applications
- Smallest form factor (6.9 mm x 6.9 mm)
- Reference design to reduce certification costs

SX-PCEAC2
Wi-Fi 5 + Bluetooth 5.0 PCIe Module
- For high throughput applications (867 Mbps)
- Multiple form factors:
- Surface Mount (M.2 LGA Type 1216)
- M.2 1630 PCI Express Card
- Mini PCI Express Card

SX-USBAC
Wi-Fi 5 + Bluetooth 5.0 USB Module
- For OEMs needing long product lifecycle and revision control
- Embedded form factor options:
- Surface mount
- USB Type-A connector

SX-590
Wi-Fi 5 System on Module for Enterprise Applications
- On-chip TCP/IP stack with enterprise security
- Minimal development time
- For medical applications

SX-590-1402
FIPS Compliant Wi-Fi 5 System on Module
- FIPS 140-2 cyptographic module
- RS-232 or ethernet to Wi-Fi connectivity
- For US governmental, medical facilities

SX-ULPGN-BTZ
Wi-Fi 4 + Bluetooth 5.0 + 802.15.4 Module
- Eliminate need for external MPU
- Integrated multi-radio coexistence
- For embedded IoT

SX-59HLS
Wi-Fi 4 System on Module for IoT Applications
- On-chip TCP/IP stack with enterprise security
- Minimal development time
- For ultra low power applications

BR-330AC-LP
Low power Wi-Fi 5 Ethernet to Wi-Fi Bridge
- WPA2 Enterprise security
- 5V power input, possibly powered by USB bus
- Mounting hole for system integration

SX-BR-4600WAN2
Wi-Fi 4 2x2 Ethernet to Wi-Fi bridge
- Widely adopted in medical
- Proven in large healthcare facilities
- Long-term firmware update support

DS-510
USB2 – USB Device Server Over Ethernet
- Long seller USB device server for USB over IP access
- Most affordable solution
- Proven with industrial OEM partners

DS-600
USB3 – Enterprise USB Device Server Over Ethernet
- Secure USB over IP data transfer over network
- USB 3 port support for higher performance
- NAS support with USB mass storage device

DS-700
USB3 – USB Device Server Over the Internet
- Successor of DS-510 with USB 3 over IPv6
- USB device access over Internet
- OEM customization for non-Windows clients

DS-700AC
USB3 – USB Device Server Over Wi-Fi
- USB device access through WLAN – IPv4/IPv6
- USB device access over Internet
- OEM customization for non-Windows clients

SD-300
Serial Device Server Over Ethernet
- Serial over IP solution
- eCable mode to emulate long-distance serial communication over IP network
- Custom option for RS-422/RS-485

SD-330AC
Serial Device Server Over Wi-Fi 5
- Serial over IP solution over Wi-Fi 5
- eCable mode to extend serial communication wirelessly
- Custom option RS-422/RS-485

SD-330AC-1402
FIPS 140-2 validated Serial/Ethernet Bridge
- Serial over IP solution over Wi-Fi 5
- Ethernet device integration into WLAN
- Solutions for governmental institutes

AP-500AC
Wi-Fi 5 3x3 Dual-Band Access Point
- 1.3Gbps maximum bit rate for high-data bandwidth WLAN
- WDS for WLAN coverage expansion
- Multi-SSID/VLAN support for enterprises

SX-PCEAN2
Wi-Fi 4 Mini PCIe Module
- Industrial temperature support
- 2x2 MIMO performance with 300 Mbps data rate
- Ideal for high performance applications based on the NXP i.MX6 platform

CBR-100AC
CAN Bridge Over Wi-Fi for Vehicles
- CAN data IP protocol conversion for Wi-Fi data transfer
- CAN data logging to support vehicle troubleshooting
- CAN bus wire replacement by wireless link

FBR-100/FBR-100AN
CNC Machine Protocol Converter
- Compatible with major CNC machines
- Multiple protocol support, MTConnect, OPC-UA, and ModbusTCP
- Secure CNC machine integration into the network
